Grommets
Cable Laid – Vertical, Choker, or Basket Hitches. Rated capacities shown apply only to 6X19 and 6X36 classification EIPS wire rope.
Quality Philosophy
Warnings and Cautions
Federal Specifications
Sales Conditions
| RATED CAPACITY IN TONS (2,000 LBS.) | ||||||
|---|---|---|---|---|---|---|
| GROMMET BODY DIAMETER | VERTICAL | CHOKER | VERTICAL BASKET | 60˚ | 45˚ | 30˚ |
 |  |  |  |  |  | |
| COMPONENT ROPE 6X36 BRIGHT IWRC EIPS RRL | ||||||
| 3/4″ | 6.2 | 4.1 | 12 | 11 | 8.8 | 6.2 |
| 7/8″ | 8.3 | 5.4 | 17 | 14 | 12 | 8.3 |
| 1″ | 11 | 6.8 | 21 | 18 | 15 | 11 |
| 1-1/8″ | 13 | 8.4 | 26 | 22 | 18 | 13 |
| 1-1/4″ | 16 | 10 | 31 | 27 | 22 | 16 |
Rated capacities shown apply only to 6X19 and 6X36 classification EIPS wire rope.
WARNING: Prop 65: Products supplied by Advantage Sales & Supply Co. LLC may expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information, visit to www.P65Warnings.ca.gov.
All images are for illustrative purposes only. Actual products may vary in appearance, features, and specifications without notice.
