Harrington CB Chain Hoists
- Thick die-cast aluminum body
- High-strength, heat-treated main pinion shaft and load gear
- Positive braking action with Weston-style load brake incorporating two moisture-resistant brake pads with four braking
- Smooth running, pre-lubricated ball bearings, and precision machined drive train components
- Fewer parts for an easy-to-work-on design
- 10-foot lift is standard, 15- and 20-foot lifts are also stocked; nonstandard lifts and hand chain drops available as well.
- Grade 100 heat-treated manganese alloy load chain resists abrasion and wear while minimizing chain weight.
- Forged and heat-treated alloy steel hooks are designed to open slowly and not fracture under excessive loads.
- Test certificate verifies that every hoist has been factory load tested to 125% of rated capacity, in accordance with ASME B30.16 requirements.
Quality Philosophy
Warnings and Cautions
Federal Specifications
Sales Conditions
| Cap. (tons) | Product Code | Headroom C (in) | Std. Lift (ft) | Pull to Lift Load (lbs.) | Overhaul Ratio |
Load Chain Dia. (mm.) x Chain Fall Lines | Net Weight (lbs.) | Shipping Weight Approx (lbx.) | Weight for Add’l One Foot of Lift (lbs.) |
|---|---|---|---|---|---|---|---|---|---|
| 1/2 | CB005 | 11.2 | 8 | 48 | 25 | 5.0 x 1 | 24 | 25 | 1.0 |
| 1 | CB010 | 11.6 | 8 | 58 | 43 | 6.3 x 1 | 28 | 29 | 1.2 |
| 1 1/2 | CB015 | 13.8 | 8 | 70 | 57 | 7.1 x 1 | 35 | 36 | 1.4 |
| 2 | CB020 | 14.8 | 8 | 72 | 70 | 8.0 x 1 | 45 | 47 | 1.6 |
| 2 1/2 | CB025 | 16.5 | 8 | 66 | 99 | 9.0 x 1 | 60 | 62 | 1.8 |
| 3 | CB030 | 20.1 | 8 | 72 | 114 | 7.1 x 2 | 54 | 58 | 2.1 |
| 5 | CB050 | 23.6 | 8 | 68 | 198 | 9.0 x 2 | 91 | 95 | 3.0 |
| 8 | CB080 | 30.3 | 8 | 75 | 297 | 9.0 x 3 | 133 | 140 | 4.1 |
| 10 | CB100 | 29.9 | 12 | 72 | 396 | 9.0 x 4 | 176 | 194 | 5.3 |
| 15 | CB150 | 40.2 | 12 | 74 | 594 | 9.0 x 6 | 331 | 353 | 7.6 |
| 20 | CB200 | 46.5 | 12 | 72 x 2 | 396 x 2 | 9.0 x 8 | 503 | 657 | 10.6 |
| 30 | CB300 | 51.2 | 12 | 86 x 2 | 495 x 2 | 9.0 x 10 | 665 | 864 | 12.9 |
| 40 | CB400 | 58.3 | 12 | 86 x 2 | 693 x 2 | 9.0 x 14 | 1033 | 1364 | 17.6 |
| 50 | CB500 | 61.4 | 12 | 98 x 2 | 792 x 2 | 9.0 x 16 | 1382 | 1713 | 19.9 |
| 80 | CB800 | 100.8 | 12 | 86 x 4 | 693 x 4 | 9.0 x 28 | 3298 | – | 35.2 |
| 100 | CB1000 | 125.2 | 12 | 98 x 4 | 792 x 4 | 9.0 x 32 | 6419 | – | 39.9 |
Scroll right for more information >
| Cap. (tons) | Product Code | a (in) | b (in) | d (in) | e (in) | f (in) | g (in) | x (in) |
|---|---|---|---|---|---|---|---|---|
| 1/2 | CB005 | 6.2 | 6.3 | 8.0 | 2.7 | 3.9 | 1.1 | 3.5 |
| 1 | CB010 | 6.4 | 6.3 | 8.0 | 2.8 | 3.9 | 1.1 | 4.0 |
| 1 1/2 | CB015 | 6.7 | 7.2 | 8.0 | 3.1 | 4.4 | 1.3 | 4.7 |
| 2 | CB020 | 7.2 | 8.0 | 8.0 | 3.4 | 4.9 | 1.4 | 4.9 |
| 2 1/2 | CB025 | 7.6 | 9.2 | 8.0 | 3.6 | 5.6 | 1.6 | 5.4 |
| 3 | CB030 | 6.7 | 9.3 | 8.3 | 3.1 | 6.4 | 1.7 | 5.8 |
| 5 | CB050 | 7.6 | 11.1 | 10.0 | 3.6 | 7.6 | 1.8 | 6.8 |
| 8 | CB080 | 7.6 | 14.7 | 10.3 | 3.6 | 10.0 | 2.9 | 10.8 |
| 10 | CB100 | 7.6 | 17.2 | 14.9 | 4.4 | 12.1 | 2.9 | 11.7 |
| 15 | CB150 | 10.6 | 19.4 | 15.9 | 4.7 | 13.3 | 3.1 | 12.6 |
| 20 | CB200 | 14.7 | 29.4 | 16.3 | 7.4 | 14.7 | 3.2 | 13.8 |
| 30 | CB300 | 15.9 | 29.4 | 16.3 | 8.0 | 14.7 | 4.1 | 15.7 |
| 40 | CB400 | 19.8 | 29.9 | 16.6 | 9.9 | 15.0 | 3.8 | 17.5 |
| 50 | CB500 | 21.4 | 31.3 | 16.6 | 10.7 | 15.7 | 4.0 | 18.4 |
| 80 | CB800 | 29.9 | 55.2 | 15.9 | 13.8 | 27.6 | 5.1 | – |
| 100 | CB1000 | 31.3 | 56.9 | 14.6 | 15.7 | 28.4 | 7.3 | – |
